Combine the trusted intelligence of APT controllers with custom multi-channel LED modules from Arkalumen to enable amazing dynamic spectrum control to high power applications. The Helux APT controllers expand the power limits for DC-DC multi-channel control up to 1200W, enabling high power intelligent systems ideal for applications like dynamic spectrum horticulture and RGBW spot lights in stadiums.
Key Features
Helux controllers convert high wattage constant voltage DC source to up to 5 constant current outputs
Simple architecture centralizes power and interface control functions
Independent control of each channel
No perceivable flicker
IP65 rated option available
High power LED modules can be custom designed for the dimensions, spectra, and intensity required
LED modules optimized with APT controllers can maximize efficiency & minimize thermal issues
Product Information
Control Protocol
DMX/RDM
Casambi BLE
Form Factor
IP65 Rated option
Linear
Square
Product Specs
Up to 5 output channels
200-1200W options
2.5-15A per channel
5-45A total current
Key Markets
Horticulture
Stadium Lighting
Film & Television
Product Chart
| APT Controller | Input Driver | # of Output Channels | Control Protocol | Form Factor | Max Wattage | Max Voltage | Max Channel Current | Max Total Current |
| APT-HX5-VA-BK | CV | 5 | DMX/RDM | IP65 rated, Aluminum | 1,200W | 60V | 2@15A 3@5A |
45A |
| APT-HX5-VWC-BK | CV | 5 | Casambi BLE | IP65 rated, Aluminum | 1,200W | 60V | 2@15A 3@5A |
45A |
| APT-CV2-VA-SQ-HP | CV | 2 | DMX/RDM | Square | 200W* | 60V* | 2.5A* | 5A* |
| APT-CV2-VA-LN-HP | CV | 2 | DMX/RDM | Linear | 200W* | 60V* | 2.5A* | 5A* |
| APT-CV4-VA-SQ-HP | CV | 4 | DMX/RDM | Square | 400W* | 60V* | 2.5A* | 10A* |
| APT-CV4-VA-LN-HP | CV | 4 | DMX/RDM | Linear | 400W* | 60V* | 2.5A* | 10A* |
* Preliminary
APT Programmable Chart
| APT Controller | Control Protocol | Retrieve Settings | Dim-to-Warm | Dim-to-Off | Fade-to-Off | Set Max Current | CCT Ranges | CCT Mapping | Intensity Mapping |
| APT-HX5-VA-BK | DMX/RDM | ||||||||
| APT-HX5-VWC-BK | Casambi BLE | ||||||||
| APT-CV2-VA-SQ-HP | DMX/RDM | ||||||||
| APT-CV2-VA-LN-HP | DMX/RDM | ||||||||
| APT-CV4-VA-SQ-HP | DMX/RDM | ||||||||
| APT-CV4-VA-LN-HP | DMX/RDM |
APT Programmer
HORTICULTURE
Let Your Plants React, Go Beyond Static Spectrum
Helux high power systems add spectrum flexibility to horticultural fixtures, allowing for the implementation of custom spectra recipes that can change over the grow cycle, for different plants or even on a daily cycle. With the design of a custom LED module optimized for the APT controllers and the desired spectra and intensities, calibrated outputs can be achieved in a simple and flexible architecture.
STADIUM LIGHTS
Simplify High Intensity Color Control
Helux high power systems have no perceivable flicker and are ideal for high intensity solutions that will be used to project light on people and surfaces on camera. Each color channel can be controlled independently from a central management system or calibrated configurations can be saved locally. With the design of a custom LED module optimized for the APT controllers, thermal issues in the fixtures can be minimized and the overall system can maximize efficiency.
Resources
FAQ
No, channels do not need to have their forward voltages matched as each channel is controlled independently. There are limits to the voltage difference between the input voltage from the constant voltage driver and the forward voltage of the LED channel that are approved. Please see the applicable Data Sheet.
Yes, Arkalumen can configure the controllers before shipping. If you provide your desired configuration settings, Arkalumen will provide a unique internal code that is part of the part number that can be ordered.
Yes, the Helux controllers can be configured using the APT Programmer. Please see the APT Programmer page for more details.
Yes. The APT-HX5 comes with a DMX512/RDM input as standard and Casambi BLE Mesh is an optional addition.
APT-HX5 controllers use an IP65 rated encasement, which is rated as dust tight and protected against water projected from a nozzle.
